刀具直径Central measurement: 0,1 to 80 mmTangential measurement from above: 0,1 to 98 mmTangential measurement, lateral: 0,1 to 122 mm
|
|
应用领域
|
Tool Measurement
|
|
刀具直径
|
Central measurement: 0,1 to 80 mm
Tangential measurement from above: 0,1 to 98 mm
Tangential measurement, lateral: 0,1 to 122 mm
|
|
输入信号
|
Square-wave signals 24 V
· Transmission enabling: ENABLE 0
· Receiver enabling 1: ENABLE 1
· Receiver enabling 2: ENABLE 2
|
|
输出信号
|
Square-wave signals 24 V
· Dynamic triggering signal: DYN
· Static triggering signal: STA
· Proper laser function: LASER OK
|
|
电源
|
24 V / 160 mA
|
|
电气连接
|
M23 flange socket (male), 12-pin, on the side or bottom
|
|
固定
|
Within the machine work envelope
|
|
防护等级 IEC 60529
|
IP 68 (when connected, with sealing air)
|
|
Werkzeugreinigung
|
Blower
|
|
工作温度
|
10°C to 40 °C
|
|
存放温度
|
0°C to 50 °C
|
|
重量
|
approx. 0.95 to 1.00 kg (including blower)
|
|
