应用领域
|
Tool Measurement
|
|
刀具直径
|
Central measurement: 0,03 to 37 mm
Tangential measurement: 0,03 to 44 mm
|
|
输入信号
|
Square-wave signals 24 V
· Transmission enabling: ENABLE 0
· Receiver enabling 1: ENABLE 1
· Receiver enabling 2: ENABLE 2
|
|
输出信号
|
Square-wave signals 24 V
· Dynamic triggering signal: DYN
· Static triggering signal: STA
· Proper laser function: LASER OK
|
|
电源
|
24 V / 160 mA
|
|
电气连接
|
M23 coupling (male),12-pin, at side
|
|
固定
|
Within the machine work envelope
|
|
防护等级 IEC 60529
|
IP 68 (when connected, with sealing air)
|
|
Werkzeugreinigung
|
Blower
|
|
工作温度
|
10°C to 40 °C
|
|
存放温度
|
0°C to 50 °C
|
|
重量
|
Approx. 4.4 kg (without cable)
|
|
